Olivetti PR 4 - Notes and Meaning of the Parameters

SETUP from the Operator Console 3-5
Notes and Meaning of the Parameters
The values in bold are the factory default values.
EMULATION
: TMU 950
- TM 950
Emulation type.
I/O Interface menu (Input/Output)
SERIAL Serial interface parameters menu selection.
BIT
:
7 -
8
Data format, 7 or 8 bits.
BAUD
: 9600
- 4800 - 2400 - 1200
Data transmission/reception rate.
STOP
: 1
- 2
Number of stop bits.
PARITY
:
NONE - ODD -
EVEN
Parity control type.
HANDSHAKE: DTR -
XON/XOFF
Data handshaking protocol
RX ERROR:
PRINT ?
- IGNORED
Data receive error: print a "?" or ignore.
NATION:
CP 437
- CP 850 ...
Character set national variants
CPI: 12 -
15
- 17.1
Print pitch selection, expressed as a number of
characters per inch.
CUTTER:
YES
- NO
Receipt cutter enabled (YES) or disabled (NO).
EPSON CUTTER:
YES
- NO
Epson compatible receipt cutter enabled (YES) or
disabled (NO).
If DISABLED, you can save paper.
CHEQUE PRINT:
REAR
- FRONT
Print on cheque rear to validate (REAR) or on
cheque front. See also the command
FS a 1
.
Note:
Operative only in EMULATION: TMU 950 with the MICR reader installed; in TM 950
EMULATION (and TMU 950 without MICR reader) this parameter is given but is not
operative.
DISPLAY:
DISABLE
- ENABLE
Display module: recognized (ENABLE) or not
(DISABLE).
Note:
Operative only in EMULATION: TMU 950; in TM 950 EMULATION this parameter is
given but is not operative.
AUTO LF
: NO
- YES
Auto line feed: (NO:disable - YES:enable)
RECEIVE BUFFER: 32 -
2048
Receive buffer size (in bytes)
BUSY OFFLINE
: YES
- NO
The printer is BUSY if it is:
- off-line or in receive buffer full (YES);
- only in receive buffer full (NO).
RS PIN6:
DISABLE
- ENABLE
ENABLE=pin 6 of the interface connector is used for
the reset signal;
DISABLE= pin 6 of the interface connector is NOT
used for the reset signal.
Note:
If RS PIN6= ENABLE, the printer is reset at MARK on the RS-232C level.
RS PIN25:
DISABLE
- ENABLE
ENABLE=pin 25 of the interface connector is used
for the reset signal;
DISABLE= pin 25 of the interface connector is NOT
used for the reset signal.
Note:
If RS PIN25= ENABLE, the printer is reset at SPACE on the RS-232C level or at
HIGH on the TTL level.
PRINT Print the current setup parameters.
SAVE Stores the presetting selected in the current SET-UP
section.
DEFAULT Restore the setup parameter values set in the factory
RESTART Reinitialize the setup procedure, without storing the
presetting set before.
