Epson TM-U950 Commands 4-7
DLE EOT n
Real-time status transmission
Hexadecimal code: 10 04 n
Range: n =1-5
Transmits the selected printer status specified by n in real time, according to the following parameters:
n=1 Transmit printer status
n=2 Transmit off-line status
n=3 Transmit error status
n=4 Transmit paper roll sensor status
n=5 Transmit slip paper status
Notes:
- The printer executes this command upon receiving it.
- When transmitting status, the printer transmits only one byte without confirming the
condition of the DSR signal.
- This command is executed even when the printer is off-line, when the receive buffer is
full, or when an error occurs.
- The status is transmitted whenever the data sequence of (10)H (04)H n (n=1-5) is
received. For example, in ESC * m nL nH [d]nL+ 256 x nH, d1=(10)H, d2=(04)H, d3=(1)
- This command should not be used within the data sequence of another command that
consists of 2 or more bytes. For example, if you attempt to transmit ESC 3 n to the printer,
but DTR (DSR for the host computer) goes to MARK before n is transmitted and then DLE
EOT 4 interrupts before n is received, the code (10)H for DLE EOT 4 is processed as the
code for ESC 3 (10)H.
- This code is unavailable when using the ESC = (Select peripheral device) to select the
printer to be disabled.
- When Auto Status Back (ASB) is enabled using the GS a command, the status
transmitted by the DLE EOT command and the ASB status must be differentiated.
- If the value of n is out of the specified range, the printer ignores this command.
n=1: Printer status
Bit Off/On Hex Decimal Function
0 Off 00 0 Not used. Fixed to Off.
1 On 02 2 Not used. Fixed to On.
2 Off 00 0 Drawer kick out signal is LOW (connector pin 3)
On 04 4 Drawer kick out signal is HIGH (connector pin 3)
3 Off 00 0 On-line.
On 08 8 Off-line.
4 On 10 16 Not used. Fixed to On.
5,6 - - - Undefined.
7 Off 00 0 Not used. Fixed to Off.
