106
EN
Menu functions (Playback menu)
4
JPEG Edit
Choose from the following options:
[Shadow Adj]: Brightens a dark backlit subject.
[Redeye Fix]: Reduces the red-eye phenomenon due to ash shooting.
[ P]: Trims an image. Use the front dial
(
r
) or rear dial (
o
) to choose the size of
the trimming and FGHI to specify the
trimming position.
O
100
%
Set
[Aspect]: Changes the aspect ratio of images from 4:3 (standard) to [3:2],
[16:9], [1:1], or [3:4]. After changing the aspect ratio, use FGHI to
specify the trimming position.
[Black & White]: Creates black and white images.
[Sepia]: Creates sepia-toned images.
[Saturation]: Increases the vividness of images. Adjust the color saturation
checking the image on the screen.
[Q]: Converts the image size to 1280 × 960, 640 × 480, or 320 × 240.
Images with an aspect ratio other than 4:3 (standard) are converted to the
closest image size.
[e-Portrait]: Compensates the skin look for smoothness.
Compensation cannot be applied in such a case that a face cannot be
detected.
5
When the settings are complete, press the Q button.
The settings are applied to the image.
6
Select [Yes] and press the Q button.
The edited image is stored in the card.
Red-eye correction may not work depending on the image.
Editing of a JPEG image is not possible in the following cases:
When an image is processed on a PC, when there is not enough space in the card
memory, or when an image is recorded on another camera.
The image cannot be resized (Q) to the larger size than the original size.
[P] (trimming) and [Aspect] can only be used to edit images with an aspect ratio of 4:3
(standard).
When [ART] is selected for picture mode, [Color Space] (P. 65) will be locked at [sRGB].

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M10 Mark II and is the answer not in the manual?

Olympus E-M10 Mark II Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeMILC Body
Sensor typeLive MOS
Image stabilizerYes
Total megapixels17.2 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)4608 x 3456
Optical zoom- x
Mounting typeScrew-threaded
Focal length range- mm
Minimum aperture number-
Focus adjustmentAuto/Manual
Auto Focus (AF) points81
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modesAperture priority AE, Auto, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Camera shutter typeMechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed1/800 s
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVC, AVI, H.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemstereo
Audio formats supportedPCM, WAV
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1037000 pixels
Magnification1.15 x
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesBeach, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editingResizing, Trimming
Photo effectsBlack&White, Sepia
White balanceAuto, Cloudy, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny, Tungsten, Underwater
Playback modesRotation, Slideshow
Camera playbackMovie, Single image, Slide show
Image processorTruePic VII
Self-timer delay2, 12 s
Battery typeBLS-5
Battery life (CIPA standard)320 shots
Number of batteries supported1
Product colorBlack
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)30 - 90 %
Bundled softwareViewer 3
Weight and Dimensions IconWeight and Dimensions
Depth45.9 mm
Width119.1 mm
Height82.3 mm
Weight396 g
