Olympus E-M10 Mark II User Manual

121 EN
Menu functions (Custom menus)
4
Z Record/Erase
Option Description
g
Quick Erase
If [On] is selected, pressing the  button in the playback
display will immediately delete the current image.
—
RAW+JPEG Erase Choose the action performed when a photograph recorded
at a setting of RAW+JPEG is erased in single-frame
playback .
[JPEG]: Only the JPEG copy is erased.
[RAW]: Only the RAW copy is erased.
[RAW+JPEG]: Both copies are erased.
• Both the RAW and JPEG copies are deleted when
selected images are deleted or when [All Erase] (P. 110) is
selected.
55, 82,
88
Priority Set Choose the default selection ([Yes] or [No]) for confi rmation
dialogs.
—
a EVF
Option Description
g
EVF Auto Switch If [Off] is selected, the viewfi nder will not turn on when you
put your eye to the viewfi nder. Use the u button to choose
the display.
—
EVF Adjust Adjust viewfi nder brightness and hue.
Brightness is automatically adjusted when [EVF Auto
Luminance] is set to [On]. The contrast of the information
display is also adjusted automatically.
—
EVF Style Choose the viewfi nder display style. 133
V Info Settings
Like the monitor, the viewfi nder can be used to display
histograms, highlights and shadows, and level gauge. The
level gauge is available when [Style 1] or [Style 2] is set in
[EVF Style].
—
EVF Grid Settings Choose the type and color of framing grid displayed in the
viewfi nder when [Off] is selected for [Apply Settings to EVF]
and [Style 1] or [Style 2] is selected for [EVF Style]. Choose
the framing grid from [w], [x], [y], [X], [x] or [1].
—
V Half Way Level
If set to [Off], the level gauge will not be displayed when the
shutter button is pressed halfway down. The level gauge is
available when [Style 1] or [Style 2] is set in [EVF Style].
—
S-OVF Select [On] for a viewfi nder display similar to an optical
viewfi nder. Selecting [S-OVF] makes the details in shadows
easier to see.
•
is displayed in the viewfi nder when [S-OVF] starts.
• The display is not adjusted for settings such as white
balance, exposure compensation, and picture mode.
—
MENU
G Z
MENU
G a

Olympus E-M10 Mark II Specifications

General

Megapixel	16.1 MP
Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	17.2 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	4608 x 3456
Optical zoom	- x
Mounting type	Screw-threaded
Focal length range	- mm
Minimum aperture number	-
Focus adjustment	Auto/Manual
Auto Focus (AF) points	81
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Camera shutter type	Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/800 s
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	stereo
Audio formats supported	PCM, WAV
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Magnification	1.15 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Beach, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny, Tungsten, Underwater
Playback modes	Rotation, Slideshow
Camera playback	Movie, Single image, Slide show
Image processor	TruePic VII
Self-timer delay	2, 12 s
Battery type	BLS-5
Battery life (CIPA standard)	320 shots
Number of batteries supported	1
Product color	Black
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Bundled software	Viewer 3

Weight and Dimensions

Depth	45.9 mm
Width	119.1 mm
Height	82.3 mm
Weight	396 g
