143

Connecting the camera to a computer and a printer

Custom printing

Connect the camera to the printer using the supplied USB cable and turn the

camera on.

• When the camera is turned on, a dialog should be displayed in the monitor prompting

you to choose a host. If it is not, select [Auto] for [USB Mode] (P. 117) in the camera

custom menus.

Follow the operation guide to set a print option.

Selecting the print mode

Select the type of printing (print mode). The available print modes are as shown below.

Print Prints selected pictures.

All Print

Prints all the pictures stored in the card and makes one print for

each picture.

Multi Print

Prints multiple copies of one image in separate frames on a single

sheet.

All Index Prints an index of all the pictures stored in the card.

Print Order

Prints according to the print reservation you made. If there is no

picture with print reservation, this is not available.

Setting the print paper items

This setting varies with the type of printer. If only the printer’s STANDARD setting is

available, you cannot change the setting.

Size Sets the paper size that the printer supports.

Borderless

Selects whether the picture is printed on the entire page or inside a

blank frame.

Pics/Sheet

Selects the number of pictures per sheet. Displayed when you have

selected [Multi Print].

Selecting pictures you want to print

Select pictures you want to print. The selected pictures can

be printed later (single-frame reservation) or the picture

you are displaying can be printed right away.

100

123-3456

152017.01.01 12:30:002017.01.01

Single Print More

Select Print

Print f

Prints the currently displayed picture. If there is a picture that [Single

Print C] reservation has already been applied to, only that reserved

picture will be printed.

Single Print C

Applies print reservation to the currently displayed picture. If you

want to apply reservation to other pictures after applying [Single

Print C], use HI to select them.

More E

Sets the number of prints and other items for the currently displayed

picture, and whether or not to print it. For operation, refer to “Setting

printing data” in the next section.

Questions and Answers:

Need help?

Do you have a question about the Olympus E-M10 Mark II and is the answer not in the manual?

Olympus E-M10 Mark II Specifications

General

Megapixel	16.1 MP
Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	17.2 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	4608 x 3456
Optical zoom	- x
Mounting type	Screw-threaded
Focal length range	- mm
Minimum aperture number	-
Focus adjustment	Auto/Manual
Auto Focus (AF) points	81
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Camera shutter type	Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/800 s
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	stereo
Audio formats supported	PCM, WAV
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Magnification	1.15 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Beach, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny, Tungsten, Underwater
Playback modes	Rotation, Slideshow
Camera playback	Movie, Single image, Slide show
Image processor	TruePic VII
Self-timer delay	2, 12 s
Battery type	BLS-5
Battery life (CIPA standard)	320 shots
Number of batteries supported	1
Product color	Black
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Bundled software	Viewer 3
