75
EN
Shooting
2
Shooting slow/ quick motion movies
You can create slow motion or quick motion movies. You can set the recording speed
using nc in record mode.
1
Press the Q button to display the LV super control panel.
2
Use FGHI to select [nK].
3
Use the front dial to select
24
C4K
(custom record
mode) (P. 56), then press the Q button.
The option selected for [Slow or Fast Motion] can be
changed by pressing the INFO button. In HI, select
[Slow or Fast Motion] and then press FG to select a
magni cation factor and press the Q button. Increase
the multiplication factor to shoot a quick motion movie.
Reduce the multiplication factor to shoot a slow motion
movie. The frame rate changes accordingly.
F
+
RAW
FullHD
sRGB
+0.8
A
+
1
Natural
G
+
1
S
-
AF
F
250250 F5.6
1:02:031:02:03
10231023
0.00.0
100
%
n
+
1
+
1
S
Normal
S-IS Auto
M-IS Auto
WB
Auto
ISO
Auto
o
4
Press the R button to start shooting.
• Press the R button again to end shooting.
The movie will be played back at a xed speed so that it appears to be in slow motion
or quick motion.
Sound will not be recorded.
Any picture mode art lters will be canceled.
Either or both of slow motion and quick motion cannot be set for some options of [nK].
The shutter speed is limited to values faster than 1/24 seconds when using autofocus.
This limitation will not be applied when using manual focus.
The shutter speed is limited to values faster than 1/24 seconds when using P, A, or S
mode in movie shooting.
• When using M mode in movie shooting, the shutter speed is limited according to
autofocus or manual focus. The focus mode cannot be switched from manual to
autofocus.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M10 Mark II and is the answer not in the manual?

Olympus E-M10 Mark II Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeMILC Body
Sensor typeLive MOS
Image stabilizerYes
Total megapixels17.2 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)4608 x 3456
Optical zoom- x
Mounting typeScrew-threaded
Focal length range- mm
Minimum aperture number-
Focus adjustmentAuto/Manual
Auto Focus (AF) points81
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modesAperture priority AE, Auto, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Camera shutter typeMechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed1/800 s
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVC, AVI, H.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemstereo
Audio formats supportedPCM, WAV
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1037000 pixels
Magnification1.15 x
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesBeach, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editingResizing, Trimming
Photo effectsBlack&White, Sepia
White balanceAuto, Cloudy, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny, Tungsten, Underwater
Playback modesRotation, Slideshow
Camera playbackMovie, Single image, Slide show
Image processorTruePic VII
Self-timer delay2, 12 s
Battery typeBLS-5
Battery life (CIPA standard)320 shots
Number of batteries supported1
Product colorBlack
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)30 - 90 %
Bundled softwareViewer 3
Weight and Dimensions IconWeight and Dimensions
Depth45.9 mm
Width119.1 mm
Height82.3 mm
Weight396 g
