Olympus ESG-400 - Footswitch with Two Pedals; Footswitch with One Pedal (Optional)

ESG-400
5-8 Footswitch with two pedals
The footswitch with two pedals (Olympus REF: WB50402W) is included in delivery.
1.
Cut pedal (yellow color)
This pedal is used to activate the selected cutting mode.
2.
Coagulation pedal (blue color)
This pedal is used to activate the selected coagulation mode.
3.
Footswitch plug
Connects the footswitch with the electrosurgical generator on the rear panel.
5-9 Footswitch with one pedal (optional)
The footswitch with one pedal (Olympus REF: WB50403W) is an optional item which may be purchased
separately.
1.
Coagulation pedal (blue color)
This pedal is used to activate the selected coagulation mode.
2.
Footswitch plug
Connects the footswitch with the electrosurgical generator on the rear panel.
1.
2.
3.
1.
2.
7.022.211 / ISSUE 5 28 / 110 Chapter 1: PRODUCT SPECIFICATIONs
