Olympus ESG-400 - Inspection Equipment and Preparation

ESG-400
1 Jigs, Tools, and Measuring Equipment for Inspection
No.
Name
Model/REF
Specifications/Remarks
J001
Electrical safety tester
e.g.: Seculife ST, Unimet 1000 ST
(Bender), QA-90 (Metron)
J002
Electrosurgical analyzer
e.g.: QA-ES (Metron)
J003
Digital multimeter
DC accuracy: < 1 %,
DC voltage range 500 V
J004
Load resistors
(low power)
low inductive part, short time load 5 Ω, 140
Ω, 170 Ω all 0.5 W (or more) and 1 %
tolerance or alternatively: resistor decade
box
J005
Load resistors
(high power, low inductive)
WB979015
Low inductive part,
75 Ω, 500 Ω (300 W, 5%)
7 Ω, 916 Ω, 10 kΩ (100 W, 1%)
OR
ESG-Testbox
J007
Cables, 4 mm to 4 mm (banana)
Connection cable: monopolar or bipolar
output (1 x 4 mm) to various equipment (1
x 4 mm, banana plug), length 1 m
WARNING:
A connection of a 4 mm plug to any other
receptacle except the right-hand-side
receptacle of the MONOPOLAR 1 socket
and the MONOPOLAR 2 socket may
destroy the socket during activation.
J008
Cable, UNIVERSAL to 4 mm (banana)
WB979008
Connection cable: bipolar UNIVERSAL to
various equipment (1 x 4 mm, banana
plug), length 1 m
J009
Cable, Monopolar 1 including handswitch
WB979013
Connection Cable: monopolar output incl.
handswitch to various equipment (1 x 4
mm, banana plug), length 3…4 m
J010
Cable, Monopolar 2 including handswitch
WB979014
Connection Cable: monopolar output incl.
ha
ndswitch to various equipment (1 x 4
mm, banana plug), length 3…4
J011
Cable, neutral electrode
(P-cord) to 2 x 4 mm (banana)
WB979002 Connection cable: neutral electrode output
(2 x 2.5 mm, 10 mm, P-cord) to various
equipment (2 x 4 mm, banana plug), length
1 m
J012
Cable, Communication
MAJ-1871 Communication cable, length 0.25 m
J013
Crocodile clips (with 4 mm connection)
For connection to Potential Equalization
bonding
J014
ESG-400 foot switch double pedal
WB50402W
J015
ESG-400 foot switch single pedal
WB50403W
J016
Power Cord
Ordering depending on country. Refer to
Chapter 1-4-2
J057
Oscilloscope
e.g.: DSOX2024A (Agilent)
J058
High Voltage Probe
Attenuation: 100:1
Max. Input Voltage ≥ 850 Vp
J059
Adapter Universal Socket
W5106278
Connection cable: bipolar UNIVERSAL to
various equi
pment (3 x 4 mm, banana
plug)
7.022.211 / ISSUE 5 74 / 110 Chapter 5: Inspection
