ESG-400
Nr. Test type / mode Pwr.
level
Load
resistance
Requirement Measured
value
Test passed
Effect Yes No
Patient leakage current
12 Normal condition (NC), AC N/A N/A ≤ 0.01 mA
13 Normal condition (NC), DC N/A N/A ≤ 0.01 mA
14
Single fault condition (SFC),
AC
N/A N/A ≤ 0.05 mA
15
Single fault condition (SFC),
DC
N/A N/A ≤ 0.05 mA
Current and power consumption and output waveform
16 PureCut
300
500 Ω I
L
≤ 10 A
Eff. 3
17 Amplitude fluctuation
300
500 Ω Δ ≤ 110 V
Eff. 3
18 SalineCut
320
75 Ω S
L
≤ 1500 VA
Eff. 3
High frequency leakage current
19
Monopolar PureCut
(neutral electrode terminal)
300
500 Ω ≤ 150 mA
Eff. 3
20
Monopolar PureCut
(active electrode terminal)
300
500 Ω ≤ 150 mA
Eff. 3
21
Monopolar SprayCoag
(neutral electrode terminal)
120
500 Ω ≤ 150 mA
Eff. 3
22
Monopolar SprayCoag
(active electrode terminal)
120
500 Ω ≤ 150 mA
Eff. 3
23
Monopolar PureCut
(neutral electrode terminal)
300
unloaded ≤ 150 mA
Eff. 3
24
Monopolar PureCut
(active electrode terminal)
300
unloaded ≤ 150 mA
Eff. 3
25
Monopolar SprayCoag
(neutral electrode terminal)
120
unloaded ≤ 150 mA
Eff. 3
26
Monopolar SprayCoag
(active electrode terminal)
120
unloaded ≤ 150 mA
Eff. 3
7.022.211 / ISSUE 5 98 / 110 Chapter 5: Inspection
