9
Measurement screen
■ Explanation of the measurement screen
No. Item
1 Measurement method icon
2
Cursor
Specifies a measurement point or reference point.
3 Left image area
4
Point
Indicates a specified measurement point or reference point.
5
Object distance
The distance from the distal end of the insertion tube to the cursor position is
displayed.
The object distance mark (
) (see “Spot ranging screen” (page 80)) is displayed.
6
Right image area
The three most recent measurement results are displayed (but only one
measurement result is displayed for the Area/Lines measurement method). The
object distance mark ( ) (see “Spot ranging screen” (page 80)) indicating the
object distance to the measurement point is displayed on the right side of the
measurement value.
7 Corresponding point
IPLEX G Lite
83
