Olympus IPLEX G Lite - 11 Specification of Measurement Points; Specifying and Moving Measurement Points

11
Specification of measurement points
■ Specifying and moving the measurement points
To move the cursor, operate the [MEAS/OK] joystick by pushing it toward the direction that you
want to move the cursor to. Press the [MEAS/OK] joystick and specify the number of measuring
points needed for each method of measurement in the image area on the left.
The object distance measured at the cursor position (distance between the distal end of the
stereo optical adapter and the measurement area) and measurement results are always
displayed.
Note that the object distance showing “-. - - - mm”, indicates that the correct reference point was
not automatically acquired.
■ Re-specifying a measurement point
If the incorrect measured points were specified by mistake, select [CLEAR] in the measurement
menu.
■ Re-specifying all measurement points
If you want to restart measuring on the image from the beginning, select [ALL CLEAR] in the
measurement menu and clear all specified points.
IPLEX G Lite
87
