DMTA-20043-01EN [U8778624], Rev. B, May 2013
24 Chapter 2
2.5.2 Acquisition Indicator Light
The acquisition indicator light is located below the Play key ( ). The color of this
light indicates the operating mode of the OmniScan SX (see Table 4 on page 24).
2.5.3 Alarm Indicator Lights
There are three alarm indicator lights located on the upper right corner of the
OmniScan SX. These lights only flash one color (red) and indicate the trigger status of
their respective alarms (set within the software).
For more details about the alarm indicator lights, refer to the OmniScan MXU Software
User’s Manual.
2.6 Left Side Panel
The left side panel of the OmniScan SX (see Figure 2-2 on page 25) contains various
input and output ports.
Flashing green • The OmniScan SX is in sleep mode.
• The OmniScan SX is in sleep mode and battery
charging is complete.
Flashing red A critical factor (excessive temperature, very weak battery,
etc.) requires immediate attention.
Table 4 Acquisition indicator light statuses
Off Inspection mode
Orange Analysis mode
Table 3 Power indicator light statuses (continued)
