Replace the battery only with an Olympus battery (P/N: OMNI-A-BATT2
[U8760059]).
3.4.2.1 Battery Status Indicators
The battery status indicators located on the upper left corner of the display screen use
one of the following two methods to indicate the amount of power remaining in each
battery (see Figure 3-5 on page 38):
• The remaining operation time is displayed on the battery status indicator. The
OmniScan SX must be operated for approximately 15 minutes before it is able to
accurately display this information.
• The charge indicator (bar) on the battery status indicator shows the approximate
amount of remaining power in the battery.
If you attempt to start the OmniScan SX using a battery with an insufficient charge,
the power indicator light will flash red for approximately three seconds. To operate
the OmniScan SX, replace the battery or plug in the DC power adaptor.
Figure 3-5 Battery charge status
3.4.2.2 Battery Discharge
The battery status indicator displays the amount of time needed to discharge the
battery.
The OmniScan SX software informs the user of the remaining power status. The
battery status indicator variations are described in Table 5 on page 39.
