Figure 2-6 Rear panel of the OmniScan SX
• To prevent the OmniScan SX from falling over, the support stand must be opened
to its maximum position when the instrument is desktop mounted.
• In order to prevent injury, do not place your fingers between the rear panel and
the instrument’s support stand (when unfolded).
• Injury can result when support stand is folded in stored position.
• Do not use the support stand as a handle. Using the support stand as a handle
could cause equipment damage or injury.
Support stand
Heat sink
Support stand fastener
