DMTA-20043-01EN [U8778624], Rev. B, May 2013
Specifications 55
• To reduce the risk of electric shock, avoid touching the inner conductor of the
probe connectors. Up to 340 V can be present on the inner conductor of the UT
connectors, and up to 115 V can be present on the PA connector. The warning
symbol near the probe connectors signals this electric shock risk.
• Reinforced insulation must be provided for the probes connected to the
OmniScan SX instrument.
Use only compatible Olympus probes.
Digital input 4 digital inputs TTL, 5 V
Digital output 3 digital outputs TTL, 5 V, 15 mA
maximum per output
Remote
communication
Remote communication RS-232: 2 serial
ports using 3-wire RS-232
Acquisition on/off
switch
Through configuration of a digital
input
Power output line 5 V nominal, 500 mA (short-circuit
protected)
Pace input 5 V, TTL pace input
Table 7 OmniScan SX alarms
Alarms
Number of alarm
zones
3
Conditions Any logical combination of gates
Table 6 OmniScan SX general specifications (continued)
