Figure 3-4 The OmniScan SX DC power adaptor plug
3. Connect the DC power adaptor to the OmniScan SX DC power adaptor plug (see
Figure 3-4 on page 37).
4. Press the power key to start the OmniScan SX.
3.4.2 Lithium-Ion Battery
The OmniScan SX holds one lithium-ion battery (P/N: OMNI-A-BATT2 [U8760059]).
The lithium-ion battery can be inserted and removed without needing to shut down
the OmniScan SX, provided that there is another valid power source available (DC
power adaptor).
The OmniScan SX also includes a lithium coin battery that does not need to be
removed or replaced by the user. The coin battery keeps the instrument clock and
masterboard configuration running.
