Basic Operation 45
Figure 3-7 Attaching a ferrite clamp filter to a cable (example shown with the
scanner interface cable)
Figure 3-8 OmniScan SX connection diagram — ferrite clamp filters
3.6 OmniScan SX Software Installation
The OmniScan SX software installation is designed to be as trouble-free as possible.
The software is stored on an SDHC card.
UT probe
connections
SVGA output
USB
connection
Scanner interface
PA probe connection
