44 Chapter 3
•Olympus UT probes
•Olympus PA probe
Devices connected to the VGA out connector
USB devices connected with a USB cable (printers, etc.)
•Scanner interface
If the ferrite clamp filters are not attached, the OmniScan SX unit may fail to comply
with the international and European electromagnetic emission specifications.
To attach the clamp filters
Make sure that the cable is not clamped in between the pawls of the ferrite clamp
filter.
Attach the ferrite clamp filters as closely as possible to the cable ends. The ferrite
clamp filters are not effective unless they are immediately adjacent to the cable
end connected to the OmniScan SX.
Use the ferrite clamp filter with the corresponding cable diameter. The filter must
not slip easily or be difficult to clip onto the cable.
Make sure that the two ferrite clamp-filter parts are closed tight until the clamp
clicks.
1. Attach the ferrite clamp filter on the cable of the Olympus UT probes, in close
proximity to the connector for the OmniScan SX.
2. Attach the ferrite clamp filter on the cable of the Olympus PA probe, in close
proximity to the connector for the OmniScan SX.
3. Attach the ferrite clamp filter to the VGA cable, in close proximity to the
connector for the OmniScan SX.
4. Attach the ferrite clamp filter to the USB cable, in close proximity to the connector
for the OmniScan SX.
5. Attach the ferrite clamp filter to the scanner interface cable, in close proximity to
the connector (LEMO) for the OmniScan SX.
Figure 3-7 on page 45 and Figure 3-8 on page 45 show the applicable connection for
various cables on the OmniScan SX, and the locations where the ferrite clamp filters
must be attached.
