Olympus STM7 User Manual

4
The following symbols are placed on the product.
Study the meaning of the symbols and always use the equipment in the safest possible manner.
Symbol Meaning
Indicates a non-specific general hazard. Follow the cautions given after this symbol or
in the instruction manual.
Be careful not to pinch your fingers at the stage or the stage holder.
Indicates that the main switch is ON.
Indicates that the main switch is OFF.
Caution labels
Cautions are displayed at the areas where special cautions are required when in use and operation. Be sure to follow
the instructions.
Positions of
caution labels
· Upper area of the stage X-axis knob
· Upper area and lower area of the motorized frame
(STM7-SFA/STM7-MFA/STM7-LFA) Z-axis guide.
· Lower area of both sides of the column of the
motorized frame (STM7-SFA/STM7-MFA/STM7-LFA)
[Caution against
pinching]
When caution labels are dirty or peeled off, contact Olympus for replacement or inquiries.
CAUTION - Safety symbols -
STM7-CS50/STM7-CS100
STM7-SFA/STM7-MFA STM7-LFA
STM7-CS200/STM7-CS300
When the stage moves to
in the arrow direction, your
hands or fingers may be
pinched.
Focusing unit
opening
Focusing unit
opening
When the focusing unit
moves vertically, your
hands or fingers may
be pinched between
the focusing unit and
the focusing unit
opening or the stopper.
Stopper
Stopper
Stopper
Stopper
