STM7
} The external processing device can be connected using the
DSUB25Pin female cable.
Contact Olympus for details.
} The printer can be connected using the RS-232C interface
(DSUB9Pin male) of STM7.
Contact Olympus for details.
} When the foot switch is connected to FOOT SW connector of
the control box STM7-CB/STM7-CBA, the counter data can be
transmitted to the controller or the printer, etc. by pressing the foot
switch.
3-12 External processing device
3-13 Printer
3-10 Foot switch
} With the basic software STM7-BSW, various measurements can be
performed and measurement results can be saved.
For details, refer to the instruction manuals provided with Basic
software / MIA,EFI option software.
3-11 Basic software
