17
STM7
Stage
STM7-CS50/STM7-CS100/
STM7-CS200/STM7-CS300
Control box
STM7-CB/STM7-CBA
Hand switch
STM7-HS
Rotatable stage
Y-axis knob
Indicator
Pilot lamp
ON: The main switch is ON.
OFF: The main switch is OFF.
Emergency stop switch
(STM7-CBA only)
Y-axis clutch lever
X-axis knob
X-axis clutch lever
ON/OFF button
Z-RESET button
CALL button
DATA/HALF button
SET button
LED SEL button
Reflected light illumination/
Transmitted light illumination/
Focus navigator unit
Main switch
“
”: ON. “ ”:OFF.
INTENSITY button
X-RESET button
Y-RESET button
All-RESET button
} The names of operating portions of the control box for motorized STM7-CBA are illustrated below. The names of the
operating portions of the control box for manual STM7-CB are same.
