Mounting the objective (MM6C-VL)
} When using the reflected light arm MM6C-VL, only one objective
can be attached because the reflected light arm does not use a
revolving nosepiece.
MM6-OB series objective
Mount the desired MM6-OB series objective
k
into the objective
mount
j
by screwing in firmly.
UIS2 (UIS) brightfield series objective
Screw in the objective conversion adapter BD-M-AD
l
into the
objective mount
j
, then mount the desired UIS2 (UIS) brightfield
objective
m
on the BD-M-AD by screwing in firmly.
· The UIS2 (UIS) brightfield/darkfield objective cannot be
used because this results in flare.
· Do not attach the objective to the objective lens mount that
has been removed from the reflected light arm, or do not
attach the removed objective lens mount, with the objective
mounted, back to the reflected light arm.
j
k
l
m
