4.4 Connecting the lift’s commands
4.4.1 Hydraulic connections
Ref.
Description
Dimension
1
LIFT POWER SUPPLY
3/8” PIPE
3
LT POWER SUPPLY
1/4” PIPE
Connect the pipe 3 to the hydraulic block A..
Connect the pipe 1 to the pipe fitting B.
A
B
1
1
B
3
