4.8 Checks before use
Having completed installation of the table, the following tests must be performed before it can be used for work:
FINAL TESTING
The static and dynamic load tests with overloads are performed at the Manufacturer's premises.
The user may perform nominal load tests (with a 10% tolerance admitted for maximum valve calibration) with distribution of the loads as described
in the Loading conditions paragraph of the installation, use and maintenance manual.
TESTS
STANDARDS
1
Table levelling using spirit level.
Max 0.5 mm per metre.
2
Sturdiness of anchors fastening to the floor.
Tightening torque (50 Nm)
3
Pneumatic connections.
Diagram (see: Pneumatic diagram paragraph)
Air leakage
4
Hydraulic connections.
Diagram (see: Hydraulic Diagram paragraph)
Oil leakage
Pressure
5
Wiring.
Diagram (see: Wiring Diagram).
6
Safety devices.
(See: Safety device features paragraph)
7
The compressed air system must be powered by filtered and lubricated air
Presence of a filtering system.
8
Oil level.
Oil level rod
9
Direction of rotation of motor.
Arrow on motor
10
Plant cable and piping protection.
Cable and pipe runs provided.
11
In case of upstroke from opposite side to the torsion bar.
Presence of up ramp (optional).
12
Never load vehicles whose overall dimensions exceed those of the lift.
Loading conditions (see paragraph: Loading
conditions)
13
Never load vehicles weighing more than the lift's nominal capacity.
Capacity indicated on plate.
