A-2 Appendix A: Parts
Part Link Table
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
53-7146 PCB/solenoid metal mount
PCB/solenoid metal plate
BKT, SOLENOID, MOUNT, ERB
Cable Assembly
Configuration
Return Door Solenoid
Printed Circuit Board
(PCB)
53-7147 PCB/solenoid plate BRACKET, STRIKE, PLATE, ERB
Cable Assembly
Configuration
Return Door Solenoid
Printed Circuit Board
(PCB)
53-7149 I/O cover plates BKT, I/O, SHIELD, ERB
Cable Assembly
Configuration
Anesthesia
Workstation (AWS) G3
53-7152
53-7157
53-7161
mounting brackets
mounting plate
BKT, HALF-CELL, MOUNT, ERB
BKT, MOUNT, 1,2,3-CELL, ERB
MOUNT, OMNIRX, ERB
Mounting Brackets
One-, Two-, and
Three-Cell Cabinets
OmniRx
53-7156 metal retainer; metal retaining bracket BRACKET, AUX CUTOUT, ERB
ERB Components
Anesthesia
Workstation (AWS) G3
53-7159 AWS bracket BKT, ANESTHESIA, MOUNT, ERB
Anesthesia
Workstation (AWS) G3
53-7264 LED bracket mount BKT, LED, MOUNT, ERB, COST REDUCTION
Access Door
56-7019 foam pad LINER, FOAM, PAD, ERB
ERB Components
81-1302 corrugated slit tubing TUBING,CORRUGATED,SLIT,ID=0.650",OD=0.816"
Cabling for the
OmniTT G4
91-2051
91-2052
strain relief
grommet
STRAIN RELIEF, HEYCO, #1244
STRAIN RELIEF, HEYCO, #1207
ERB Components
Cable Assembly
Configuration
Anesthesia
Workstation (AWS) G3
91-2053 plug cover PLUG, HEYCO, #2503
ERB Components
Cable Assembly
Configuration
Part # Part Name Agile Description Where Used
