Appendix A: Parts
Part Link Table
This table links the part mentioned in the taxt to the Agile description and part number.
Part # Part Name Agile Description Where Used
15-7088-20 solenoid ASSY, BIN SOLENOID, LONG STROKE, DRAWER, ER
Return Door Solenoid
Access Door
40-3013 PCB PCB ASSY, GEN. PURPOSE AUX,FLEXLOCK, ERB
Printed Circuit Board
(PCB)
42-1336-01
42-1336-02
adapter cable
ERB adapter cable assembly
ERB PC4 Adapter Cable Assembly
CABLE ASSY,ERB,FLEXLOCK,PC4,ADAPTER,CTPC,RX,AWS
CABLE ASSY,ERB,FLEXLOCK,PC4,ADAPTER,AWS-E
Anesthesia
Workstation (AWS) G3
Cabling for the AWS
G4
42-7052 AUX cable connector; cable; AUX cable
assembly
ERB retrofit cable assembly
CABLE ASSY, RETROFIT-AUX, ERB
Cabling for the
OmniTT G3
Cabling for the AWS
G3
42-7053 power - communications cable
4 ft. cable assembly
ERB cable assembly
Molex connector
,ERB cable connector (white)
ERB power/comm cable
CABLE, ASSY, PWR/COMM, 12
ERB Components
Cable Assembly
Configuration
Anesthesia
Workstation (AWS) G3
42-7058 AUX Connector
retrofit AUX cable assembly
CABLE, ASSY, RETROFIT, AUX, CT, ERB
ERB Components
Anesthesia
Workstation (AWS) G3
50-2102
51-2057
51-2059
transport handle
OmniRx transport handle
HANDLE,TRANSPORT,FRAME
HANDLE,TRANSPORT,INTERNAL OMNI,2
HANDLE,TRANSPORT,HALF-CELL
OmniTT
OmniRx
Half-Cell
51-7042 Adjustable mounting bar BAR,HOLY,ACCESSORY RACK ANESTHESIA
Attaching the ERB in
the Upper Position
53-2116 AWS-E back bracket PANEL, UPPER REAR, AWS-E
Attaching the ERB in
the Upper Position
53-2119 ERB mount bracket BRACKET, MOUNT, ERB, RH/LH, AWS-E
Attaching the ERB in
the Upper Position
53-2135 RFI cover COVER, ERB PC BOARD, RETROFIT
53-7144 return door DOOR, RETURN, ERB
ERB Components
53-7145 access door HOUSING ASSY, ERB
ERB Components
