Installation Instructions 2-23
Installation on G3 Cabinets
Cabling for One-, Two-, and Three-Cell G3 Cabinets
1. Pull out the PC box.
Figure 2-58. PC box pulled out
2. Lift and remove the PC box lid.
Figure 2-59. Lifting the lid
3. Remove the two AUX connectors.
Figure 2-60. AUX connector locations—inside and outside of PC box
