Appendix A: Parts A-7
ERB Kits
20-6109 ERB/FLEXLOCK, G4 CONSOLE INSTALLATION KIT
42-1336-02 CABLE ASSY,ERB,FLEXLOCK,PC4,ADAPTER,CTPC,RX,AWS
1
91-1006 CLAMP,CABLE,NYLON,.375
1
91-2051 STRAIN,RELIEF,HEYCO,1244
1
94-7421-08 SCREW,PH,TORX-T10,M3X0.5X8,SEMS-INT TOOTH-7.35/
6.85,STL/ZN
1
95-6007 CABLE,TIE,4,IN.
2
20-6110 ERB FACTORY INSTALLATION KIT (for OmniRx G4)
53-7161 MOUNT,OMNIRX,ERB
94-6060 NUT,HEX,8-32,SS
94-6203 SCREW,BH,TORX,8-32,X,7/8,SS
20-6111 ERB FACTORY INSTALLATION KIT (for OmniTT G4)
94-6060 NUT,HEX,8-32,SS
94-6203 SCREW,BH,TORX,8-32,X,7/8,SS
20-6112 ERB FACTORY INSTALLATION KIT (for 1/2 cell G4)
53-7152 BKT,HALF-CELL,MOUNT,ERB
94-6060 NUT,HEX,8-32,SS
94-6151 SCREW,FH,TORX,8-32,X,1/4,SS T15
20-6119 ERB INSTALLATION KIT (a la carte for G4) Used to install an ERB in the
field on all G4 products
except ANT-FRM-001
42-1336-01 CABLE ASSY,ERB,FLEXLOCK,PC4,ADAPTER,CTPC,RX,AWS
42-1336-02 CABLE ASSY,ERB,FLEXLOCK,PC4,ADAPTER,AWS-E
42-7053 CABLE,ASSY,PWR/COMM,12'
51-7034 HANDLE,OMNITT/RX,MOUNT,ERB
51-7035 HANDLE,1,2,3-CELL,MOUNT,ERB
53-7152 BKT,HALF-CELL,MOUNT,ERB
53-7157 BKT,MOUNT,1,2,3-CELL,ERB
53-7161 MOUNT,OMNIRX,ERB
91-1006 CLAMP,CABLE,NYLON,.375
91-2051 STRAIN,RELIEF,HEYCO,1244
94-6060 NUT,HEX,8-32,SS
94-6151 SCREW,FH,TORX,8-32,X,1/4,SS T15
94-6203 SCREW,BH,TORX,8-32,X,7/8,SS
94-7421-08 SCREW,PH,TORX-T10,M3X0.5X8,SEMS-INT TOOTH-7.35/
6.85,STL/ZN
95-6007 CABLE,TIE,4,IN.
Table A-1. ERB Parts (3 of 4)
Kit # Part # Item Description Notes Qty
