Precautions for Correct Use
8
EtherCAT Communication Unit USER’S MANUAL (3G3AX-MX2-ECT)
Precautions for Correct Use
Follow the inverter mounting direction restrictions.
If this EtherCAT Communication Unit is installed, the inverter Modbus-RTU communication becomes
disabled.
Comply with the local ordinance and regulations when disposing of the product.
• After installing this EtherCAT Communication Unit to the inverter, warning labels are pasted on the
product as shown in the following illustration.
• Be sure to follow the instructions.
(Notes) The overall appearance varies depending on the inverter capacity.
The warning description is written in English when it is shipped from the factory.
Affix the Japanese warning label included with the product if necessary.
Installation
Modbus-RTU communication
Product Disposal
Warning Label Location
Warning Description
