2 - 11
2 Starting a Sample System
EtherCAT Communication Unit USER’S MANUAL (3G3AX-MX2-ECT)
2-3 CJ1W-NCx82 Master Setting
2
2-3-1 Mounting the CJ1W-NCx82
2-3 CJ1W-NCx82 Master Setting
Connect the SYSMAC CJ2-series PLC and the CJ1W-NCx82 Master Unit by fitting their connectors
together. For specific details on mounting onto the SYSMAC Unit and the control panel of the SYSMAC
Unit, refer to the User Manual for the SYSMAC CJ2 series.
Perform the settings for the CJ1W-NCx82 Master Unit. For the setting method of each component, refer
to the manual for the Master Unit.
For the setting tool, use CX-Programmer Ver. 9.2 or later.
2-3-1 Mounting the CJ1W-NCx82
2-3-2 CJ1W-NCx82 Setting
