4 - 11
4 Inverter Control
EtherCAT Communication Unit USER’S MANUAL (3G3AX-MX2-ECT)
4-3 Control with the Independent Profile
4
4-3-3 Control Method
 Command
 Frequency reference
 Status
The 16-bit data is as shown below.
 Output frequency monitor
Bit and data information
7 10
Bit Name Meaning
0 Forward/stop 0: Stop
1: Forward command
1 Reverse/stop 0: Stop
1: Reverse command
7Fault reset
: Resets an error or trip for the unit or inverter.
- Reserved Set 0.
Name Meaning
Frequency reference Specify the frequency reference in increments of 0.01 Hz. When a value is set that
exceeds the maximum frequency, operation is performed at the maximum frequency.
Setting range: 0 to maximum frequency
15 12 9  7 3  10
Bit Name Meaning
0 During forward operation 0: Stopped/during reverse operation
1: During forward operation
1 During reverse operation 0: Stopped/during forward operation
1: During reverse operation
3 Fault 0: No error or trip occurred for the unit or inverter
1: No error or trip occurred for the unit or inverter
7 Warning 0: No warning occurred for the unit or inverter
1: Warning occurred for the unit or inverter
9 Remote 0: Local (Operations from EtherCAT are disabled)
1: Remote (Operations from EtherCAT are enabled)
12 Frequency matching 0: During acceleration/deceleration or stopped
1: Frequency matched
15 Connection error between the
Optional Unit and inverter
0: Normal
1: Error (Cannot update data for the inverter. To restore, turn the
power supply OFF and then ON again.)
 Reserved Set 0.
Name Meaning
Output frequency monitor Displays the output frequency in increments of 0.01 Hz.
