Connectable Device Lists Appendix A
Loose Wire Crimp Connectors
I/O Connecting Cables for MULTIPLE I/O TERMINAL Units
Connectors for MULTIPLE I/O TERMINAL Units
Item Model Specifications
Socket XG5M-4032-N Compatible cable wire gauge: 24 AWG
XG5M-4035-N Compatible cable wire gauge: 28 to 26 AWG
Partial Cover XG5S-2001 Two required per connector.
Hood Cover XG5S-5022 Cannot be used with multi-drop DeviceNet connectors.
Model Specifications
(Provided with I/O Units) Cable length: 40 mm
(Provided with Communications Units) End connector
GCN1-010 Cable length: 0.1 m
GCN1-030 Cable length: 0.3 m
GCN1-040 Cable length: 0.4 m
GCN1-060 Cable length: 0.6 m
GCN1-100 Cable length: 1 m
Model Description Remarks
14-60-0032 MOLEX connectors Pressure weld con-
nection
Housing For 24 AWG
50-57-9403 Crimp connection Housing
16-02-0069 Reeled pins For 24 to 30 AWG
16-02-0086 For 22 to 24 AWG
16-02-0096 Loose pins For 24 to 30 AWG
16-02-0102 For 22 to 24 AWG
11-01-0209 Crimping Tool For 24 to 30 AWG
