127
Dimensions of Connectable Devices Appendix B
DCN1-1P Power Supply Tap
Flat Cable Connectors
DCN4-TR4-1 Flat Connector Socket
126.5
119.5
15.5
14±0.3
29.9
112.5
45.3
30.9
20.5
15.5
45
119.5±0.3
Two, 3.5 dia.
Two, 3.5 dia. or M3
Terminating Resistor
Socket (CN4)
Power Supply
Terminal Block (CN3)
Communications Cable
Connectors (CN1 and CN2)
Fuses (F1 and F2)
Mounting holes or taps
All dimensions are in mm.
22
17
17.8
All dimensions are in mm.
30.7
9.5
13.8
