Terminating Resistors
DRS1-T Terminal-block Terminating Resistor
DRS2-1 and DRS2-2 Shielded Micro-size (M12) Terminators
Note The terminating resistance (121 Ω) is connected across pins 4 and 5.
DRS3-1 Shielded Mini-size Terminator
Note The terminating resistance (121 Ω) is connected across pins 4 and 5.
30±0.2
40
20
20
DRS1-T
20
Two, 4.2 dia. or M4
Mounting holes or taps
All dimensions are in mm.
1
2
3
4
5
12
4
M12
3
5
8.5 dia.14.9 dia. 13.6 dia.
44.7
DRAIN
V+
V−
CAN H
CAN L
: NC
: NC
: NC
:
:
121 Ω
Wiring
Pin Name
All dimensions are in mm.
Pin
1
2
3
4
5
DRAIN
V+
V−
CAN H
CAN L
: NC
: NC
: NC
:
:
121 Ω
26 dia.
16
62.5
4
5
1
2
3
Name
Wiring
All dimensions are in mm.
