133
Current Consumption of DeviceNet Devices Appendix C
Note The communications current consumption indicated for Expansion Units is the additional current con-
sumed when the Expansion Unit is connected to a Basic Unit.
For example, the current consumption for a combination of a DRT2-ID16 Basic Unit and an XWT-OD16
Expansion Unit is 60 + 10 = 70 mA.
DRT1-series General-purpose Slaves
DRT2-ID16SLH 33 mA max.
DRT2-ID16SLH-1 32 mA max.
DRT2-OD16SLH 35 mA max.
DRT2-OD16SLH-1 35 mA max.
DRT2-ID32SL 100 mA max.
DRT2-ID32SL-1 90 mA max.
DRT2-OD32SL 80 mA max.
DRT2-OD32SL-1 75 mA max.
DRT2-MD32SL 80 mA max.
DRT2-MD32SL-1 80 mA max.
DRT2-ID32SLH 100 mA max.
DRT2-ID32SLH-1 105 mA max.
DRT2-OD32SLH 80 mA max.
DRT2-OD32SLH-1 85 mA max.
DRT2-MD32SLH 90 mA max.
DRT2-MD32SLH-1 90 mA max.
Model Internal current consumption Communications current consumption
DRT1-ID08 50 mA max. 30 mA max.
DRT1-ID08-1 50 mA max. 30 mA max.
DRT1-ID16 50 mA max. 30 mA max.
DRT1-ID16-1 50 mA max. 30 mA max.
DRT1-OD08 50 mA max. 30 mA max.
DRT1-OD08-1 50 mA max. 30 mA max.
DRT1-OD16 50 mA max. 30 mA max.
DRT1-OD16-1 50 mA max. 30 mA max.
DRT1-MD16 50 mA max. 25 mA max.
DRT1-ID16T 90 mA max. 30 mA max.
DRT1-ID16T-1 90 mA max. 30 mA max.
DRT1-ID16TA (Shares communications power supply.) 50 mA max.
DRT1-ID16TA-1 (Shares communications power supply.) 50 mA max.
DRT1-OD16T 90 mA max. 30 mA max.
DRT1-OD16T-1 90 mA max. 30 mA max.
DRT1-OD16TA (Shares communications power supply.) 50 mA max.
DRT1-OD16TA-1 (Shares communications power supply.) 50 mA max.
DRT1-MD16T 90 mA max. 30 mA max.
DRT1-MD16T-1 90 mA max. 30 mA max.
DRT1-MD16TA (Shares communications power supply.) 50 mA max.
DRT1-MD16TA-1 (Shares communications power supply.) 50 mA max.
DRT1-ID32ML (Shares communications power supply.) 50 mA max.
DRT1-ID32ML-1 (Shares communications power supply.) 50 mA max.
DRT1-OD32ML (Shares communications power supply.) 90 mA max.
DRT1-OD32ML-1 (Shares communications power supply.) 90 mA max.
Model Communications current consumption
