135
Current Consumption of DeviceNet Devices Appendix C
DRT2-series Analog Slaves
DRT1-series Special I/O Slaves Units
MULTIPLE I/O TERMINALs
Communications Unit
I/O Units
DRT1-WD16C 60 mA max. 30 mA max.
DRT1-WD16C-1 60 mA max. 30 mA max.
DRT1-MD16C 50 mA max. 30 mA max.
DRT1-MD16C-1 50 mA max. 30 mA max.
DRT1-B7AC 500 mA max. 70 mA max.
Model Communications current consumption
DRT2-AD04 90 mA max.
DRT2-AD04H 70 mA max.
DRT2-DA02 120 mA max.
DRT2-TS04T 70 mA max.
DRT2-TS04P 70 mA max.
Model Internal current consumption Communications current consumption
CPM2C-S100C-DRT
CPM2C-S110C-DRT
170 mA max. 30 mA max.
C200HW-DRT21 250 mA max. (Supplied from the 5 V DC base.) 45 mA max.
DRT1-232C2 100 mA max. 50 mA max.
Model Internal current consumption Communications current consumption
DRT1-COM 110 mA max. 30 mA max.
Model I/O Unit interface current consumption Internal and I/O current consumption
GT1-ID16(-1) 35 mA max. ---
GT1-ID16MX(-1) 35 mA max. ---
GT1-ID16ML(-1) 35 mA max. ---
GT1-ID16DS(-1) 35 mA max. ---
GT1-ID32ML(-1) 55 mA max. ---
GT1-OD16(-1) 35 mA max. 9 mA max.
GT1-OD16MX(-1) 35 mA max. 9 mA max.
GT1-OD16ML(-1) 35 mA max. 9 mA max.
GT1-OD16DS(-1) 35 mA max. 9 mA max.
GT1-OD32ML(-1) 65 mA max. 11 mA max.
GT1-ROP08 40 mA max. 350 mA max. (Inrush current 30 A max.)
GT1-ROS16 50 mA max. 250 mA max. (Inrush current 30 A max.)
GT1-AD04 50 mA max. Internal power supply: 100 mA max.
(Inrush current 20 A max.)
GT1-AD08MX 50 mA max. Internal power supply: 100 mA max.
(Inrush current 30 A max.)
GT1-DA04 50 mA max. Internal power supply: 150 mA max.
(Inrush current 20 A max.)
GT1-DA04MX 50 mA max. Internal power supply: 100 mA max.
(Inrush current 30 A max.)
GT1-TS04T 50 mA max. Internal power supply: 80 mA max.
(Inrush current 10 A max.)
Model Internal current consumption Communications current consumption
