Revision History
08 December 2003 Changes were made throughout the manual to
include information on new models, including
connectors, T-branch taps and DRT2-series
Smart Slaves. “PC” was also changed to “PLC”
throughout the manual as the abbreviation for
Programmable Controller.
Pages 4, 5, 6: Added (-V1) suffix to models in
table.
Page 7: Added reference for DRT2-series mod-
els.
Pages 11, 12: Added table of information on
DRT2-series General-purpose Slaves.
Pages 41, 43: Added new connector models to
tables.
Page 44: Added applicable DRT2-series mod-
els to note.
Page 45: Added new T-branch Tap models to
table,
Pages 46, 47: Added diagrams of new T-branch
Tap models.
Page 53: Changed and added new information
on cables and connectors.
Page 54: Added information for connectors
without screws.
Page 56: Added information on new connector
model.
Page 63: Changed “SYSMAC” to “PLC.”
Pages 83, 84: Added tables on DRT2-series
Smart Slaves.
Page 86: Added information on new models to
table of communications cables and connectors.
Page 87: Changed information in table of crimp
terminals for communications cables.
Pages 87, 88: Added information on new mod-
els to tables of single-branch and three-branch
taps
Pages 93, 94: Added dimensional diagrams for
new connector models.
Pages 95, 96: Added diagrams of new T-branch
Tap models.
Pages 101, 102: Added tables of information on
DRT2-series Smart Slaves
09 November 2004 Minor changes were made, mainly to restruc-
ture information in tables of device lists, add
information and correct minor errors, as follows:
Page xiv: Added information on changing oper-
ating mode.
Pages 11, 12, 90, 92, 111, and 113: Added new
models to tables.
Pages 28 and 65: Added information on power
supply.
Page 37: Changed resistance values from “60
Ω” to “70 Ω” and from “200 to 300 Ω” to “300 Ω
or higher.”
Page 55: Changed “S82H-series and S82J-
series” to “S82J-series and S82K-series.”
Pages 91 and 112: Moved DRT1-series Analog
Slaves to separate table after DRT1-series Ana-
log Slaves.
Page 106: Changed width from “11” to “12” in
diagram.
10 August 2005 Page v: Information on general precautions notation added.
Page xi: Information on liability and warranty added.
11 April 2008 Changes were made throughout the manual to add the DRT2-series Slave Units and Special Flat
Cable, to correct errors, and to add descriptions.
Revision code Date Revised content
