DeviceNet-compatible Devices Section 1-2
1-2-3-3 MULTIPLE I/O TERMINAL Units
Unit I/O
points
Words allocated in
PLC memory
I/O connec-
tions
Unit
power
supply
voltage
Instal-
lation
Model
number
Remarks
Input Output
Communications
Unit
None Two sta-
tus words
0 words None 24 V DC
(sup-
plied
from
outside)
DIN
track
DRT1-COM ---
Basic
I/O
Units
Transis -
tor Input
Units
16 input
points
1 word 0 words M3 terminal
block
GT1-ID16 NPN
GT1-ID16-1 PNP
16 input
points
1 word 0 words Connector
(made by
MOLEX)
GT1-ID16MX NPN
GT1-ID16MX-1 PNP
16 input
points
1 word 0 words Connector
(made by
FUJITSU)
GT1-ID16ML NPN
GT1-ID16ML-1 PNP
16 input
points
1 word 0 words Connector
(D-sub, 25
pin)
GT1-ID16DS NPN
GT1-ID16DS-1 PNP
32 input
points
2 words 0 words High-density
connector
(made by
FUJITSU)
GT1-ID32ML NPN
GT1-ID32ML-1 PNP
Transis -
tor Out-
put Units
16 output
points
0 words 1 word M3 terminal
block
GT1-OD16 NPN
GT1-OD16-1 PNP
16 output
points
0 words 1 word Connector
(made by
MOLEX)
GT1-OD16MX NPN
GT1-OD16MX-1 PNP
16 output
points
0 words 1 word Connector
(made by
FUJITSU)
GT1-OD16ML NPN
GT1-OD16ML-1 PNP
16 output
points
0 words 1 word Connector
(D-sub, 25
pin)
GT1-OD16DS NPN
GT1-OD16DS-1 PNP
32 output
points
0 words 2 words High-density
connector
(made by
FUJITSU)
GT1-OD32ML NPN
GT1-OD31ML-1 PNP
Relay
Output
Units
8 output
points
0 words 1 word M3 terminal
block
GT1-ROP08 ---
16 output
points
0 words 1 word M3 terminal
block
GT1-ROS16 ---
