Omron fh series User Manual

Setting Item
Set value
[Factory default]
Description
Relocate memo-
ries
• [Relocate]
• Do not relocate
Select the relocate processing.
*1
• Relocate: Relocate processing is executed. More units can
be registered to one Scene group because this function
improves the memory efficiency.
*2
- At startup.
- When the Scene group is selected.
- When the Processing Unit is added.
- When Scene or Processing Unit is copied.
- When scene data, such as registered, or re-registered
Model, or Measurement region is changed.
It is normally recommended to use Relocate
• Do not relocate: Relocate processing is not carried out.
Set this setting when Relocate processing takes long time.
*3
*1. For FH series/FHV series, Relocate memories setting is invalid.
*2. Relocate processing could be take time depends on relocated data capacity or data fragmentation
when Relocate is selected.
*3. An error may occur; e.g. data is insufficient because data relocate processing is not carried out
when Do not relocate is selected. For data memory region, refer to A-9 About Memories Usable with
FH series/FHV series on page A - 29.
4 Setting the Controller
4 - 5
FH/FHV Series Vision System User’s Manual (Z365-E1)
4-2 Setting the Status at Startup [Startup Settings]
4

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
