Confirmation of overwrite dialog box is displayed.
4 Click Yes.
Confirmation of overwrite dialog box is displayed.
5 Select a loading method.
Overwrite:
Click Continue.
Read into the new folder:
Click Read into the new folder and enter the folder name in the text box. Click Continue.
Saving a scene
1 Select the Scene tab on the Edit flow screen.
5 Creating Measurement Scenes
5 - 37
FH/FHV Series Vision System User’s Manual (Z365-E1)
5-5 Using Variables to Edit the Flow [TDM Editor]
5
5-5-3 Editing Scenes [TDM Editor]
