If you select Save to memory + FTP Server as a Destination, configure the setting items be-
low.
Item
Set value
[Factory default]
Description
IP address a.b.c.d
a: 1 to 223
b: 0 to 255
c: 0 to 255
d: 0 to 255
[1.0.0.0]
Specify the IP address of the destination FTP server.
Connection via a proxy server cannot be made.
User name [Anonymous] Specify the user name which is used for a connection with
the destination FTP server. Use only single-byte alphanumer-
ic characters and numbers.
Password - Enter the password for a connection with the destination FTP
server.
Port number [21] Enter the port number for a connection with the destination
FTP server.
Connection meth-
od
• [Active]
• Passive
Select the FTP connection method.
Folder name - Specify the destination directory of the FTP server. Use the
relative pathname of the destination directory.
Use only single-byte alphanumeric characters and numbers.
5
Specify the prefix of the image logging file.
Item
Set value
[Factory default]
Description
Prefix - Set the prefix for the saved file name. (Maximum number of
characters: 32 single-byte characters)
The set character string is added at the beginning of the
name of the save file.
Use only single-byte alphanumeric characters and numbers.
If a prefix contains a non-supported character, a logging error
is generated when logging is executed.
6 When you use the function to switch the saving folder, set the switching conditions.
Item
Set value
[Factory default]
Description
Switch saving fold-
er by scene
• Checked
• [Unchecked]
If this is checked, folders that correspond to scene numbers
are automatically created and image files are divided by
scene and saved.
Use scene name
as folder names
• Checked
• [Unchecked]
If this is checked, folders to which image files are allocated
are named using the scene names and scene group names
at the time of measurement execution.
If a scene name contains a character not supported for folder
names, a logging error is generated when logging is execut-
ed.
The following symbols can not be used in the file or folder
names.
¥ / : , ; * ? " < > |
If these symbols are used, a logging error is generated when
logging is executed.
6 Performing Measurement and Adjustment
6 - 12
FH/FHV Series Vision System User’s Manual (Z365-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
