Item
Set value
[Factory default]
Description
Switch saving fold-
er by judge.
• Checked
• [Unchecked]
If this is checked, OK/NG folders are automatically created
and image files are divided by the overall judgment and
saved.
• Save to Memory + File Setting Example and Save Destination:
Setting example Destination
• Folder name: USB disk
• Prefix: image_
• Switch saving folder by scene.: Selected
• Switch saving folder by judge.: Selected
The settings in the example on the left are ap-
plied as shown below.
• OK image save destination:
\USBDisk\S000-000\OK\image_(Measurement
ID).IFZt
• NG image save destination:
\USBDisk\S000-002\NG\image_(Measurement
ID).IFZ
• Save to Memory + FTP Server Setting Example and Save Destination:
Setting example Destination
• IP address: 10.5.6.100
• User name: OMRON
• Password: abc
• Port number.: 21
• Connection method: Active
• Folder name: Logging
• Prefix: image_
• Switch saving folder by scene.: Selected
• Switch saving folder by judge.: Not selected
With left sample settings, the file will be saved as
below.
• When the current directory which FTP server
specifies is C:\Data\RAMDisk.
C:\Data\RamDisk\Logging\S000-000\im-
age_(Measurement ID.ifz)
Additional Information
• If logging errors occur, please check the following.
• Is the LAN cable connected properly?
• Are the destination server settings in system settings correctly set?
• Did you use any character other than single-byte alphanumeric characters for the file
names or folder names?
• Did you use the following symbols as the file or folder names?
¥ / : , ; * ? " < > |
• Measurement ID:
measurement time YYYY-MM-DD_HH-MM-SS-XXXX
(YYYY: Calendar, MM: Month, DD: Day, HH: Hour, MM: Minute, SS: Second, XXXX: Millisec-
ond and Line number)
Example:
Measurement time: 11:10:25.500 AM, December 24, 2007 and Line 0, the measurement ID is
"2007-12-24_11-10-25-5000".
Since the file name of the logging image also includes the same measurement ID, confirma-
tion of the measurement data and image data can be performed with the measurement ID.
7 Select the file type.
Set the file type to save image files. Refer to A-6 Image file on page A - 21.
6 Performing Measurement and Adjustment
6 - 13
FH/FHV Series Vision System User’s Manual (Z365-E1)
6-3 Useful Functions for Operation
6
6-3-1 Logging Measurement Values and Measurement Images [Data Logging/Image Logging]
