- When attaching the mounting fixture to the back side:

Mounting holes

- When attaching the mounting fixture to the front side:

Mounting holes

2 Attach the lighting controller.

Tightening torque: 0.15 N・m

Screws: M5 × 8 mm countersunk head screw

• When using 1ch to 4ch common type of FLV-TCC

- When attaching the mounting fixture to the back side:

Mounting holes

5 Installation

5 - 19

FHV Series Smart Camera Setup Manual (Z408-E1)

5-2 Installing the Smart Camera

5-2-2 When Connecting the Smart Camera to a Lighting Controller
