Item
FHV7H-
M004 C004 M016 C016 M032 C032 M050 C050 M063R C063R M120R C120R
External Interface
Serial RS-232C×1
Ethernet Protocol: Non-procedure (TCP/UDP)
I/F: 1000BASE-T×1
EtherNet/IP Yes (Target/Ethernet port)
PROFINET Yes (Slave/Ethernet port), Conformance class A
EtherCAT N/A
Parallel I/O NPN/PNP common
Parallel I/F High-speed input: 1, General input: 3, High-speed output: 1, General output: 4
Encoder I/F N/A
Monitor I/F N/A
USB I/F N/A
SD Card I/F microSD card: SDHC×1
Indicator
Lamps
Main PWR: Green, RUN: Green, LINK: Yellow, BUSY: Green, OR: Yellow, ERR: Red
SD SD ACCESS: Yellow
Supply Voltage 21.6 VDC to 26.4 VDC (When an I/O cable with 20 m is connected, it is 24.0 VDC to 26.4
VDC.)
Current
Consumption
With lighting modules: 4.2 A
Without lighting modules: 0.60 A
Built-in FAN N/A
Usage Environment
Ambient
temperature
range
Operating: 0 to +40℃, Storage: －25 to +65℃ (with no icing or condensation)
Ambient
humidity
range
Operating & Storage: 35 to 85%RH (With no condensation)
Ambient
atmosphere
No corrosive gases
Vibration
tolerance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration direction: X/Y/Z,
Sweep time: 8 minute/count, Sweep count: 10
With lens modules: Half amplitude: 0.15 mm (Others are the same as above.)
Shock
resistance
Impact force: 150 m/s
2
, Test direction: 6 directions, three time each (up/down, front/behind,
left/right)
Noise
immunity
Fast transient burst
・ DC power
Direct infusion: 2kV, Pulse rising: 5 ns, Pulse width: 50 ns, Burst continuation time: 15 ms/
0.75 ms, Period: 300 ms, Application time: 1 min.
・ I/O line
Direct infusion: 1kV, Pulse rising: 5 ns, Pulse width: 50 ns, Burst continuation time: 15 ms/
0.75 ms, Period: 300 ms, Application time: 1 min.
Grounding Class D grounding (100Ω or less grounding resistance) * Existing the third class grounding
3 Configuration
3 - 4
FHV Series Smart Camera Setup Manual (Z408-E1)
