• FHV7H-□□□□□-S□□-□□
30.0
36.0
4-M5.0
91.0
77.0
36.8
55.5
103.2
35.5
50.0
98.0
9.2
4-M5.0
110.0
6.0
16.7
68.52.7
12.2
20.5
22.5
69.0
35.5 35.0 35.5
36.0
30.0
50.0
98.0
OPTICAL AXIS
depth4
depth6
Mounting screw holes (The tolerance: ± 0.1 mm)
Recommenden tightening torque: 2.3N・m
5.5dia.
5.5dia.
(Unit: mm)
Additional Information
We have the 2D CAD data or 3D CAD data.
You can download CAD data from www.fa.omron.co.jp.
