Omron FHV Series User Manual

• FHV-XHD-LEM
61
61
68.4
68.4
M62x0.75DEPTH3
(21)
( 36.21)
(Unit: mm)
• Outer size when the waterproof hood, FHV-XHD-S, is mounted.
30.0
36.0
4-M5.0
68.4
126.7
68.5 2.7
36.8 35.0
55.5
114.7
60.0
35.5
50.0
98.0
9.2
4-M5.0
110.0
6.0
16.7
12.2
20.5
22.5
69.0
35.5 35.0 35.5
36.0
30.0
50.0
98.0
OPTICAL AXIS
Mounting screw holes (The tolerance: ± 0.1 mm)
depth4
depth6
Recommenden tightening torque: 2.3N・m
5.5dia.
5.5dia.
(Unit: mm)
3 Configuration
3 - 43
FHV Series Smart Camera Setup Manual (Z408-E1)
3-7 Waterproof Hoods
3
3-7-2 Dimensions
