External Reference Parameters
518
FQ2-S4 User’s Manual
142 Verifica-
tion con-
dition
Verification master data Setting/Acqui-
sition
−1: OFF
0: All master data
1: Master data 0 verification
2: Master data 1 verification
:
32: Master data 31 verifica-
tion
−1 ---
---
143 Partial verification ON/
OFF
Setting/Acqui-
sition
0: OFF 1: ON 0 --- ---
144 Verification end digit Setting/Acqui-
sition
1 to 1024 1024 --- ---
145 Verification beginning
digit
Setting/Acqui-
sition
1 to 1024 1 --- ---
150 Selected master num-
ber
Settings/
Acquisition
0 to 31 0 --- ---
152 Auto master data num-
ber
Setting/Acqui-
sition
0 to 31: Master data num-
ber
−1: OFF
−1 ---
---
161 Judge-
ment
condi-
tion
threshold
Upper limit for cell rec-
ognition rate threshold
Setting/Acqui-
sition
0 to 100 100 --- Judgement
condition
162 Lower limit for cell rec-
ognition rate threshold
Setting/Acqui-
sition
0 to 100 0 --- Judgement
condition
163 Contrast threshold
upper limit
Setting/Acqui-
sition
0 to 100 100 --- Judgement
condition
164 Contrast threshold
lower limit
Setting/Acqui-
sition
0 to 100 100 --- Judgement
condition
165 Focus threshold upper
limit
Setting/Acqui-
sition
0 to 100 100 --- Judgement
condition
166 Focus threshold lower
limit
Setting/Acqui-
sition
0 to 100 100 --- Judgement
condition
170 Output
parame-
ter
String output ON/OFF
(memory link)
Setting/Acqui-
sition
0: OFF, 1: ON 0 --- ---
171 NG error code output
(memory link)
Setting/Acqui-
sition
0: OFF, 1: ON 1 --- ---
172 Partial output ON/OFF
(memory link)
Setting/Acqui-
sition
0: OFF, 1: ON 0 --- ---
173 Output end digit (mem-
ory link)
Setting/Acqui-
sition
1 to 128 128 --- ---
174 Output beginning digit
(memory link)
Setting/Acqui-
sition
1 to 128 1 --- ---
202+3×N
(N=0 to
31)
*1
Verifica-
tion con-
dition
Master data N Setting/Acqui-
sition
32 characters max. --- --- ---
300+N
(N=0 to
31)
Reference unit number
N
Setting/Acqui-
sition
0 to 31 0 --- ---
External
refer-
ence
number
Category Data name Set/acquired Data range Default Text string
assigned
to
Ethernet
output
setting
Logged
