Chapter 10: Technical Specifications
Description Specification
Drive Train
Drive wheels 2 grey non-marking foam-filled rubber
Wheel dimensions 200 x 50 mm (7.9 x 2.0 inches) nominal
Passive Casters 2 front, 2 rear, spring-loaded
Caster diameter 75 mm (3 inches) nominal
Brakes 2 (one each axle)
Steering Differential
Performance
Description Specification
Performance
Max payload – level LD-60: 60 kg (132 lb)
LD-90: 90 kg (198 lb)
Swing radius 343 mm (13.5 inches)
Turn radius 0 mm
Translational speed, max LD-60: 1800 mm/s (70.9 inches/s)
LD-90: 1350 mm/s (53.1 inches/s)
Rotational speed, max LD-60: 180°/s
LD-90: 180°/s
Stop position accuracy ±100 mm for position, ±2° for rotation
-with the HAPS option ±10 mm for position, ±0.5° for rotation
Traversable step, max: LD-60 LD-60: 15 mm (0.6 inch)
LD-90: 10 mm (0.4 inch)
NOTE:A speed of 250 -300 mm/s for the LD-60 and 250 mm/s for
the LD-90 is required for these steps. Faster or frequent driving over
such steps or gaps will shorten the lifespan of the drivetrain com-
ponents. Lower speeds may not traverse the step. Steps should
have smooth, rounded profiles.
Traversable gap, max LD-60 and LD-90: 15 mm (0.6 inch)
Climb grade, 60 kg max 1:12
Traversable terrain Generally wheelchair accessible
Minimum floor flatness F
F
25 (based on the ACI 117 standard)
NOTE:ACI 117 is the American Concrete Institute’s standard for
11970-000 Rev H1 LD Platform OEM User's Guide 135
