Omron LD Platform

Chapter 10: Technical Specifications
Battery Outputs
Nominal Qty Actual
Maximum
Current
Description
5 VDC 1 5 VDC±5% 1 A Switched Aux power
12 VDC 1 12 VDC±5% 1 A Switched Aux power
20 VDC 1 20 VDC±5% 1 A Switched Aux power
22 - 30 VDC 2 battery 4 A Switched
22 - 30 VDC 1* battery 10 A Switched
22 - 30 VDC 1* battery 10 A Safe, Switched
* 10 A Switched and 10 ASafe, Switched share the 10 A of current.
11970-000 Rev H1 LD Platform OEM User's Guide 137
