4 - 35
4 System Program
NA-series Programmable Terminal Hardware User’s Manual (V117)
4-4 System Menu Details
4
4-4-12 Interface Settings (Device System Menu)
This screen is used to make settings for FINS.
FINS
No. Item Description
(a) Ethernet Port 1 Settings Sets the FINS network address for Ethernet port 1.
The node address is automatically created based on the IP address.
(b) Ethernet Port 2 Settings Sets the FINS network address for Ethernet port 2.
The node address is automatically created based on the IP address.
(c) FINS/UDP Port No. Displays the FINS/UDP port number.
(c)
(a)
(b)
